Professional Digital Trunking System BF-9300/9500
Channel units, base station controller and B/S dispatch platform for single-site to multi-zone trunking networks
A professional digital trunking system delivered as a network: rack-mounted channel units at the radio sites, a base station controller running the multi-carrier channel-sharing application, and a B/S dispatch management platform. Deployable from a single-site network up to multi-zone multi-site with digital IP interconnection.
Reviewed by Ellen Zhou
- System type
- Professional digital trunking system
- Composition
- Channel units + base station controller + dispatch platform
- Dispatch platform
- B/S architecture, full IP
- Network options
- Single-site to multi-zone multi-site
Overview
The BF-9300/9500 is a professional digital trunking system delivered as a network, not a single device. Three parts form the core — rack-mounted digital channel units for coverage, a base station controller running multi-carrier channel sharing, and a dispatch management platform for control-room operations — and deployment runs from a single-site network to multi-zone multi-site with digital IP interconnection.
Positioning
- System type: professional digital trunking system, sold as a complete network.
- Core parts: digital channel units, base station controller and dispatch platform.
- Coverage layer: fixed channel units provide regional coverage and cross-zone communication.
- Control layer: the controller runs multi-carrier channel sharing and network management.
- Dispatch layer: a B/S platform turns radio traffic into control-room operations.
- Use case: directed dispatch across one site or many.
Capacity and channels
- Carrier model: multi-carrier channel sharing under the base station controller.
- Channel output: 50 W per documented channel unit.
- Network growth: add channel units, talk groups and sites to the same network.
- Controller expansion: capacity expansion is a documented controller function.
- Call management: voice call management is part of the controller's duties.
- Sizing: sites, carriers per site, dispatch positions and talk groups come from the design.
System architecture
- Channel units: 19-inch 2U rack-mounted units for fixed installation in an ordinary equipment cabinet.
- Unit features: 50 W output, fault alarms, built-in power module and emergency float charging.
- Power resilience: float charging suits sites where mains power is not dependable.
- Cooling and location: active cooling and GPS/BDS positioning that supports dispatch location functions.
- Controller: central industrial-grade computer running the multi-carrier channel-sharing application.
- Controller duties: capacity expansion, bearer protocol, network transmission, equipment monitoring, voice calls and data/information management.
Networking
- Platform architecture: B/S and full-IP; dispatch positions work over the network.
- Tiered permissions: control room, mobile command post and office get different access levels, not one shared console.
- Dispatch functions: voice dispatch, GIS dispatch and real-time dynamic management.
- Information management: personnel and terminal information management.
- Management functions: patrol management, satellite positioning, historical data query and remote control.
- Deployment options: single-site, small-scale, large-scale, single-zone multi-site and multi-zone multi-site, with digital IP linking separated sites.
Installation
- Site survey: where the sites go, buildable height, cabinet or room, power and transmission.
- Customer scope: antenna, mast or tower, feeder run, cabinet or equipment room.
- Power and links: mains power with required backup plus transmission between sites and to dispatch.
- Approvals: civil works, frequency licence and trunking system approval are handled in the destination market.
- Documentation: we supply the technical documentation for the licence application.
- On-site work: local teams install and cable; our engineers configure, commission and verify coverage.
Ordering
- Quotation basis: per project, following the approved design.
- Scope drivers: sites and zones, carriers per site, dispatch positions, talk groups and services in scope.
- Coverage and links: coverage area, digital IP interconnection and band version.
- Commercial terms: price, MOQ, lead time and payment terms are agreed per project.
- No fixed figures: prices and lead times are not published on this page.
Full specification
| System type | Professional digital trunking system |
|---|---|
| System composition | Digital channel units, base station controller, dispatch management platform |
| Dispatch platform architecture | B/S architecture, full-IP technology |
| Dispatch functions | Voice dispatch, GIS dispatch, real-time dynamic management, personnel and terminal information management |
| Platform management functions | Patrol management, satellite positioning, historical data query, remote control, tiered permission management |
| Base station controller | Industrial-grade computer running the multi-carrier channel-sharing application |
| Controller functions | Capacity expansion, bearer protocol processing, network transmission management, equipment monitoring and management, voice call management, data and information resource management |
| Channel unit form | 19-inch 2U rack-mounted units for fixed installation |
| Channel unit coverage role | Regional signal coverage and cross-zone communication |
| Channel unit features | 50 W power, fault alarms, built-in power module, emergency power float charging, active cooling, GPS/BDS satellite positioning |
| Network options | Single-site trunking, small-scale trunking, large-scale trunking, single-zone multi-site, multi-zone multi-site, digital IP interconnection |
| Site preparation | Antenna and mast or tower, feeder, cabinet or equipment room, power with backup, transmission links — provided by the customer or local partner |
| Licensing | Applied for by the user or local partner in the destination market; documentation supplied by us |
| Commercial terms | System configuration and price quoted per project |
Shipping & compliance
- Lithium battery: UN38.3 test summary and SDS are available for transport.
- Type approval, FCC or CE documents depend on the model and band version; confirm at quotation.
- Project pricing on request. MOQ and lead time depend on the model and configuration.
- Warranty and spare-parts terms are confirmed in the project quotation.
Typical applications
- Public safety and emergency communications
- Government and enterprise private networks
- Police, security and command dispatch operations
- Industry, commerce and large campuses
- Utilities and infrastructure operations
- Multi-site organisations needing zone-wide dispatch
Frequently asked questions
Click a question to see the answer
What exactly is delivered in a BF-9300/9500 project?
The system is assembled from three documented parts: digital channel units at the radio sites, a base station controller in the centre, and the dispatch management platform. How many of each, which site types and which services are included depends on the project design, and the quotation lists the scope item by item.
How many sites and carriers will we need?
The site count, carriers per site, dispatch positions and talk groups come out of the coverage and traffic design. The system supports single-site trunking, small-scale and large-scale trunking, single-zone multi-site and multi-zone multi-site layouts, with digital IP interconnection for separated sites. The figures are fixed in the project design rather than quoted on this page.
What do we have to prepare on site, and who handles the frequency licence?
The customer or local partner provides the physical half of the project: antenna and mast or tower, feeder, equipment room or cabinet, mains power with the backup the operation requires, and the transmission links between sites and to the dispatch centre. Civil works, frequency licensing and trunking system approval are handled by the user or the local partner in the destination market, and we supply the technical documentation needed for the application.
Can the network be expanded later?
Yes. The base station controller is documented for capacity expansion and runs the multi-carrier channel-sharing application, so additional channel units, talk groups and sites can be added to the same network, and separated sites can be linked through digital IP interconnection.
How do dispatch positions access the platform?
The dispatch management platform uses a B/S architecture with full-IP technology, so dispatch positions work over the network instead of running the whole application locally. Server arrangement, network access and access levels are agreed during project design, and tiered permission management is part of the documented function set.
How is the system priced?
Per project. Sites, carriers, dispatch positions, coverage, interconnection requirements, band version and the division of work on site all change the scope, so price, minimum order quantity and lead time are confirmed in the quotation rather than published as fixed figures.
